M40 Multi-Minejack®- All In One Utility Vehicle

Evolutional Multi-Minejack – All-In-One Utility-Vehicle

The Multi-Minejack is an evolutionary carrier with the highest level of versatility and best utilization potential of any utility vehicle in the industry. With this design, a single all-in-one carrier can take the place of a variety of specialty vehicles in your fleet, including:

  • Fanhandler
  • Pipe hander
  • Tire changer
  • Crane truck
  • Flat deck carrier
  • Full use scissor lift

With multiple functions available, this unit is built with safety interlocks programmed into the PLC (programmable logic controller) to reduce boom speed when the deck is lifted from the deck stops. The standard model is equipped with Timberland’s exclusive hose management system.

This task truck features a 4-wheel drive centre articulated carrier with a 4-section telescopic crane, 4,000 lbs. extended deck capacity, cable trays for neat, organized storage of the boom hosing and a fold-down removable handrail system with on-board storage.

Technical Specifications
Engine
• Tier lll approved engine - 6 cylinder
• Cummins QSB6.7, 240 HP (179 kW) @2500 rpm
• Liquid-cooled, turbo charged
• 220 L (48.4 gal) fuel tank
• AKG radiator

Transmission
• Dana Clark 32,000 standard shift transmission
• Four speed forward and reverse
• 4-wheel drive

Exhaust System
• Catalytic converter w/silencer

Axles
• Dana 114 front and rear axle package

Tires
• 10:00 x 20 solid tires

Steering
• Orbital steering
• 37° Articulation each direction

Brake System
• Fully hydraulic wet disc service brakes on each axle
• Spring applied, hydraulic pressure-release wet disc secondary and park brake

Electrical System
• 24 V electrical w/ fire resistant wires
• Backup alarm (107 dB)
• Two (2) forward & Two (2) reverse LED drive lights
• Lockable master switch
• One (1) strobe light

Instrumentation
• Engine temperature & pressure warning lights
• Transmission temperature & pressure warning gauges
• Engine temperature & pressure warning gauges
• Hour meter
• Volt meter
• Parking brake applied warning light

Hydraulic System
• 99 L (21.7 gal) hydraulic reservoir
• JIC hydraulic fittings & Aeroquip hoses

General Equipment
• Front tow bumper
• Fire extinguisher bracket
• Wheel chock bracket
• Side facing operator seat
• 4 Nozzle fire suppression

Additional Options
• ROPS / FOPS canopy
• ROPS / FOPS enclosed cab includ- ing air-conditioning, heat w/ insula- tion and cab mounted lighting
• Air ride seat
• Cold weather package
• Air / water header assembly
• Fire extinguisher
• Rear tow bumper
• Front & rear tow hooks
• Tier III engine with DPF filter
• Mercedes MB904 Tier lll engine
• Cummins tier IV QSB4.5 engine
• Front & Rear lifting lugs
• Stick steering
• Front facing operator seat
• Graco or Lincoln automatic lubrication system
• Jump start receptacle
• 6 nozzle fire suppression
• Checkfire
• Firwin blanket
• HTI wrap
• Rear brake lights
• Speedometer
• Tachometer
• 120 V inverter
• Wheel chocks
• Wiggins fuel fill
• Mesabi or Copper Core radiator
• Tire chains
• 10:00 x 20 solid tires
• 10:00 x 20 pneumatic tires
• 10:00 x 20 flex tires
• Mud flaps
