Technical Specifications Engine
• Tier lll approved engine - 6 cylinder
• Cummins QSB6.7, 225 HP (167 kW) @2400 rpm
• Liquid-cooled, turbo charged
• 220 L (48.4 gal) fuel tank
• AKG radiator
Transmission
• Dana Clark 32,000 standard shift transmission
• Four-speed forward and reverse
• 4-wheel drive
Exhaust System
• Catalytic converter w/silencer
Axles
• Dana 114 front and rear axle package
Tires
• 10:00 x 20 solid tires
Steering
• Orbital steering
• 37o articulation each direction
Brake System
• Fully hydraulic wet disc service brakes on each axle
• Spring applied, hydraulic pressure-release wet disc secondary and park brake
Hydraulic System
• 99 L (21.7 gal) hydraulic reservoir
• JIC hydraulic fittings & Aeroquip hoses
Electrical System
• 24 V electrical w/ fire resistant wires
• Backup alarm (107 dB)
• Two (2) forward & Two (2) reverse LED drive lights
• Lockable master switch
• One (1) strobe light
Instrumentation
• Engine temperature & pressure warning lights
• Transmission temperature & pressure warning gauges
• Engine temperature & pressure warning gauges
• Hour meter
• Volt meter
• Parking brake applied warning light
General Equipment
• Front tow bumper
• Fire extinguisher bracket
• Wheel chock bracket
• Ansul 4 nozzle fire suppression package (LVS)
• Side facing operator seat
• Rear frame set to take any cassette
