T120-2H/4DD Tensioner

Physical Dimensions

• Maximum Pull/Tension 3 x 3,350 daN ( 7,370 lbs.)
• 1 x 10,000 daN (22,000 lbs.)
• Maximum Linespeed (Tensioning) 5 km/hr (3.1 mph)

Tensioner Bull Wheel Specifications

• Bull wheel diameter 1600 mm (63”)
• Exclusive canted axis bull wheel design
• Open side design for ease of conductor loading
• Wear resistant nylon bull wheel segments
• 6 grooves per bull wheel set with 54mm groove diameter
• Maximum conductor diameter 45.7 mm (1.8”)
