Derricks & Hoists for Heavy Construction Projects
Building on over 75-years of heavy-lifting and tensioning experience, Timberland Equipment has emerged as a leading force in the design and delivery of engineered hoists, winching and derrick systems for construction and mining projects worldwide.
Engineering and Design
Timberland designs and builds a broad product range of derricks including modular portable derricks which can be transported up and down high-rise buildings via elevator to high-capacity derricks installed on large civil and mining construction sites. From 1 to 35-ton standard derricks and heavy lift hoisting packages.
Go here to Request a Derrick Calculation | Derricks for Mining Projects
-
35 Ton Derrick
-
17 Ton Derrick
-
10 Ton Derrick
-
6 Ton Derrick
-
Custom Derricks
-
Downloads
-
Ask a Question
-
Features
-
Specs
-
Diagram
-
Ask a Question
• Adjustable sill and leg lengths
• Adjustable sill spread angle from 45° to 100°
• Standard maximum boom length of 123′-4″
• Boom, mast, sill and leg sections 8′-4″
• Lattice construction
• Sheaves have machined rope grooves and sealed anti-friction bearings
• Mechanical boom angle indicator
• Electro-hydraulic swinger drive
• Swing limit switches
• Load & boom blocks
• Multi position mast base design
• Standard hoist package allows for max lift height of 850′ fully reeved
- 8 Part line for the load line
- 10 Part line for the boom line
• Rated minimum operating temperature -20°C (-4°F)
Options
• Bolt on rigging package
• Erection Gin Pole or Crane
• Load Moment Indicator (LMI) package including:
- Anti 2-Block
- Anemometer
- Load Sensing
• Digital display of boom and swing angles
• Beacon on top of mast
• Swinger remote control (25 ft. pendant)
• Additional 25 ft. remote extensions upon request
• Cold temperature package to allow for operation down to -40°C (-40°F)
• 1800’ 35 Ton Extended Lift Height Derrick option
Have a question or need more information? We’re here to help — just fill out the form below!
-
Features
-
Specs
-
Diagram
-
Ask a Question
• Adjustable sill and leg lengths
• Adjustable sill spread angle from 45° to 100°
• Standard maximum boom length of 106′-8″
• Boom, mast, sill and leg sections 8′-4″
• Lattice construction
• Sheaves have machined rope grooves and sealed anti-friction bearings
• Mechanical boom angle indicator
• Electro-hydraulic swinger drive
• Swing limit switches
• Load & boom blocks
• Multi position mast base design
• Standard hoist package allows for max lift height of 1700′ fully reeved
• 4 Part line for the load line
• 7 Part line for the boom line
• Rated minimum operating
• Temperature -20°C (-4°F)
Options
• Bolt on rigging package
• Erection Gin Pole or Crane
• Load Moment Indicator (LMI) package including:
• Anti 2-Block
• Anemometer
• Load Sensing
• Digital display of boom and swing angles
• Beacon on top of mast
• Swinger remote control (25 ft. pendant)
• Additional 25 ft. remote extensions upon request
• Cold temperature package to allow for operation down to -40°C (-40°F)
Have a question or need more information? We’re here to help — just fill out the form below!
-
Features
-
Specs
-
Diagram
-
Ask a Question
• Fixed sill and leg length
• Fixed sill spread angle at 90°
• Standard maximum boom length of 87’-0”
• Boom, mast, sill and leg sections 6’-0”
• Lattice construction
• Sheaves have machined rope grooves and sealed anti-friction bearings
• Mechanical boom angle indicator
• Electro-hydraulic swinger drive
• Swing limit switches
• Load & boom blocks
• Multi position mast base design
• Standard hoist package allows for max lift height of 850’ fully reeved
• 4 Part line for the load line
• 6 Part line for the boom line
• Rated minimum operating temperature -20°C (-4°F)
Options
• Load Moment Indicator (LMI) package including:
• Anti 2-Block
• Anemometer
• Load Sensing
• Digital display of boom and swing angles
• Beacon on top of mast
• Swinger remote control (25 ft. pendant)
• Additional 25 ft. remote extensions upon request
• Cold temperature package to allow for operation down to -40°C (-40°F)
Have a question or need more information? We’re here to help — just fill out the form below!
-
Features
-
Specs
-
Diagram
-
Ask a Question
• Fixed sill and leg length
• Fixed sill spread angle at 90°
• Standard maximum boom length of 66′-0″
• Boom, mast, sill and leg sections 6′-0″
• Lattice construction
• Sheaves have machined rope grooves and sealed anti-friction bearings
• Mechanical boom angle indicator
• Electro-hydraulic swinger drive
• Swing limit switches
• Load & boom blocks
• Multi position mast base design
• Standard hoist package allows for max lift height of 850’ fully reeved
-- 2 Part line for the load line
-- 5 Part line for the boom line
• Rated minimum operating temperature -20°C (-4°F)
Options
• Load Moment Indicator (LMI) package including:
• Anti 2-Block
• Anemometer
• Load Sensing
• Digital display of boom and swing angles
• Beacon on top of mast
• Swinger remote control (25 ft. pendant)
• Additional 25 ft. remote extensions upon request
• Cold temperature package to allow for operation down to -40°C (-40°F)
Have a question or need more information? We’re here to help — just fill out the form below!
Fill out the form to Download the Derrick handout.
Have a question or need more information? We’re here to help — just fill out the form below!
Adjustability and Configurations
All of our standard stiffleg (fixed and adjustable) derricks can be configured into a Guyline, Column and Chicago Boom configuration.
Consult Timberland’s expert team for load capacity charts and any additional features required for your specific configuration and requirements.
Modular Construction & Standardization
Timberland’s standard modular design allows for interchangeability between boom and mast sections as well as between leg and sill sections.
Our modular component design provides balance between practical set-up of the machine and ease of handling and transport.
Customization
Timberland thrives when custom applications are required. Consult our team of highly qualified engineers and senior sales consultants for custom derrick and hoist applications.
Continued Support
Our team works hand in hand with customers and local regulatory authorities to ensure seamless project implementation.
Timberland supplies with each Adjustable Stiffleg Derrick, a computer program to show the derrick capacity and reactions for any configuration within the adjustability range. This program is also available on our website.
